KG-SW DC/Ac Square Wave Invert
KG-SW DC/Ac Square Wave Invert
Introduction
The power is often cut off in some areas, it causes a lot of electrical appliance can't be applied normally. lt shows rapid response, strong anti-interference, Stable output frequency and voltage as well as inversion charge integrated design for inverting and charging, when the commercial power is off , the inverter automatically switches into the inversion state of battery power supply, and when commercial power is on ,it automatically output commercial power and with automatic battery charging management function. This inverter has the function of battery over-voltage protection, adjustment of charge current, under voltage protection of battery during discharging, over-load protection and so on. lt works individually for 24 hrs/day without worrying about power interruption.
Specifications
| Spec | |||
|---|---|---|---|
AC Charger | 220V士10% | Electrc EnergyConversion Rate | ≥70% |
Output AC Voltage | 220V+10%(Automatic stabilizer) | Switching Mode | ≤100ms automatic switch |
Output | 50Hz±2% | Keep Emergency Time | Depending on the configurationbattery capacity and load power.ideal computational formula:Inverter crash time(h)=batterycapacity(Ah)+dischargecurrent(A)x0.7 (n) |
Output Vave | Corrective sine wave(PV square wave) | Battery Model | Outside |
| Model | DC Voltage(V) | Product size D×W×H(cm) | Package size D×W×H(cm) | Weight(kg) | Qty |
|---|---|---|---|---|---|
| KGSW-300VA | 12V124V136V148V | 26x25.5x15.5 | 34.5x32.5x24 | 9.5 | 1 |
| KGSW-350VA | 12V124V136V148V | 26x25.5x15.5 | 34.5x32.5x24 | 10 | 1 |
| KGSW-500VA | 12V124V136V148V | 26x25.5x15.5 | 34.5x32.5x24 | 12 | 1 |
| KGSW-800VA | 12V124V136V148V | 30x28x16 | 38x37x24 | 17 | 1 |
| KGSW-1000VA | 12V124V136V148V | 30x28x16 | 38x37x24 | 18 | 1 |
| KGSW-1500VA | 12V124V136V148V | 32x33x18.5 | 40x40x52 | 23.4 | 1 |
